Meta VX 4 Plus

Hybrid Single Phase Inverter | Extended PV Output

Features include increased PV power capabilities of 5600W, dual output for smart load management, and a maximum PV input current of 40A. It includes user-friendly features such as a 4.3 color LCD with a touchable button, and built-in Wi-Fi for mobile monitoring and over-the-air (OTA) firmware upgrades. Additional features include USB On-the-Go support, a built-in BMS communication port, meter calibration for optimized system operation, a battery- independent design, and a built-in anti-dust kit.

Product Inquiry
Home Products Meta VX 4 Plus
Scroll for more

Product Features

Icon

BMS Compatible

Supports lithium batteries with advanced BMS communication.

Icon

Dual output

Supports lithium batteries with advanced BMS communication.

Icon

Battery less operation

Separate outputs for essential and non-essential loads.

Icon

Built in wifi dongle

Built-in WiFi for easy real-time system monitoring.

Technical Specifications

Inverter Capacity
AC Output
PV Capacity
MPPT Range
PV Input
Battery Voltage
AC Input Voltage
Communication Port
Operating Temp (Degrees)
Dimension
Net Weight (Kg)
4000W
17A
5600W
60-450V
40A
24V
230V
USB/RS232/RS485/Wi-Fi/ Dry-Contact
-10 to 50 Degrees
136 x 300 x 400.2
10
